7
SET MODE

Time Set

SET > Time Set > Date/Time
»
MENU
Date
Sets the date (Year/Month/Day).
L The day of the week is automatically set.
Time
Sets the current time.
L The time is displayed in the 24-hour format.
NOTE: The backup battery for the internal clock
The IC-PW2 has a lithium backup battery (CR2032)
for the internal clock and timer functions.
When the backup battery is exhausted, the linear
amplifier normally works but cannot retain the
current time.
See page 9-3 for the battery replacement.
<<NTP TIME SYNC>>
Synchronizes the internal clock with a time
management server.
L To use this function, you need an Internet connection and
default gateway settings.
NTP Function
Automatically obtains the current time from an NTP
server.
NTP Server Address
Sets NTP server address.
L See page 1-8 for details on entering characters.
» SET > Time Set
MENU
UTC Offset
Sets the UTC offset time.
CLOCK2 Function
Displays the second clock on the screen.
CLOCK2 UTC Offset
Sets the time offset for Clock 2.
CLOCK2 Name
Sets the name of up to 3 characters for Clock 2.
L See page 1-8 for details on entering characters.
(Default: ON)
(Default: time.nist.gov)
(Default: ± 0:00)
(Default: ON)
(Default: ± 0:00)
(Default: UTC)

SD Card

» SET > SD Card
MENU
Load Setting
Selects the saved data file to load.
L See page 6-3 for details.
Save Setting
Saves the setting data onto an SD card.
L See page 6-2 for details.
SD Card Info
Displays the SD card capacity.
Screen Capture View
Displays the selected screen capture.
L See page 8-3 for details.
Firmware Update
Displays the Firmware Update mode.
Format
Formats the SD card.
If you use a brand-new SD card, be sure to format it in
the linear amplifier.
L See page 6-1 for details.
Unmount
Unmounts the SD card.
Before you remove a card when the linear amplifier is
ON, BE SURE to electrically unmount it. Otherwise,
the data may be corrupted or deleted. (p. 6-2)
7-6
