  • Page 1 PW1 Linear Amplifier Setup / Configuration Icom America Inc.
  • Page 2 Setting up the Icom PW1 Using the PW1 with 1 or 2 Icom exciters Physical connections (1 radio) Physical connections (2 radios) “Synchronization” Setting the ALC levels...
  • Page 3 Physical Connections (1 Icom radio) There are only 3 cables required between the PW1 and an Icom radio. (All 3 cables are included)
  • Page 4 Physical Connections (1 Icom radio) 1 “accessory” cable. (7 pin “DIN” cable)
  • Page 5 Physical Connections (1 Icom radio) 1 “remote” cable. (3.5mm “phono” cable)
  • Page 6 Physical Connections (1 Icom radio) 1 coaxial cable. (50 ohm coax, RG8, etc)
  • Page 7 Physical Connections (1 Icom radio) The IC-718, 706 series or IC-7000 will also require the optional OPC 599 adapter.
  • Page 8 Physical Connections (1 Icom radio) Connect the DIN cable to the radio’s “ACC 2” port (7 pin) ** Note that the ports on the PW1 and radio are not labeled the same**...
  • Page 9 Physical Connections (1 Icom radio) Connect the remote cable to the radio’s “remote” port...
  • Page 10 Physical Connections (1 Icom radio) Connect the coax cable to the radio’s “ANT 1” port...
  • Page 11 Physical Connections (1 Icom radio) Make sure the exciter (radio) switch is in the “1” position...
  • Page 12 Physical Connections (1 Icom radio) Connect the 7 pin DIN cable to “ACC 1” of the PW1...
  • Page 13 Physical Connections (1 Icom radio) Connect the remote cable to “remote 1” of the PW1...
  • Page 14 Physical Connections (1 Icom radio) Connect the coax cable to “Input 1” of the PW1...
  • Page 15 Physical Connections (1 Icom radio) Connect your antenna to “ANT 1” of the PW1...
  • Page 16 Physical Connections (1 Icom radio) Connect your dummy load to “ANT 4” of the PW1 (if applicable)

  • Page 17: Physical Connections

    Physical Connections (2 Icom radios) Make sure the exciter (radio) switch is in the “1 & 2” position...
  • Page 18 Physical Connections (2 Icom radios) Connect the second radio the same way, using the “2” ports of the PW1...
  • Page 19 Synchronization The PW1 will automatically change bands, as needed, when the radio frequency is changed. Synchronization may not be possible with a non-Icom radio. The synchronization commands are CI-V commands sent from the radio via the remote cable. Use of a CT-17 is not recommended with the PW1.
  • Page 20 Synchronization First, make sure your radio is off, then perform a reset of the PW1 by pressing and holding the [UP] and [DOWN] buttons while turning the PW1 on.
  • Page 21 Synchronization Now, turn the PW1 off, hold the [input] button, and turn the PW1 back on. The green “input 1” should now be flashing.
  • Page 22 Synchronization Turn on your Icom radio and rotate the tuning dial on the radio until the green “input 1” lights steady.
  • Page 23 Synchronization If using a 2 Icom radio, power off radio #1 and then press the [input] button to select “input 2”. Power on the 2 radio and adjust the radio tuning knob until the light stops blinking.
  • Page 24 Synchronization Once the radio(s) are synchronized, turn off the radio(s) and the PW1. Turn the PW1 and radio(s) back on and test by changing bands on the radio. The PW1 should automatically change bands with the radio.
  • Page 25 The final step is to set the ALC levels for the PW1. The procedure is the same for 1 or 2 Icom radios. For proper calibration of the PW1, you should use a dummy load. Make sure the load being used is capable of handling the PW1’s output...
  • Page 26 Setting ALC Levels First, carefully set the ALC adjustment pot on the rear of the PW1 to the minimum, fully counter-clockwise.
  • Page 27 Setting ALC Levels Turn on the PW1 (if not already on). Press the [amp/protect] button to turn off the PW1’s amp circuit. The green light should be off.
  • Page 28 Setting ALC Levels Make sure the proper antenna and input are selected.
  • Page 29 Setting ALC Levels Press the [tuner] button to turn on the PW1’s tuner circuit. The green light should be on.
  • Page 30 Setting ALC Levels Set the left meter to display “power” and the right to display “ALC”.
  • Page 31 Setting ALC Levels Set the radio to RTTY mode and transmit at 100 watts. You should see about 100 watts on the power meter of the PW1.
  • Page 32 Setting ALC Levels Stop transmitting and press the [amp/protect] button to turn the PW1’s amp back on. The green light should be on.
  • Page 33 Setting ALC Levels Be ready to adjust the ALC adjust screw on the PW1. Transmit from the radio and carefully adjust the ALC until the meter shows mid-scale, as shown below. Once set, stop transmitting.
  • Page 34 Setting ALC Levels Once the ALC level is set, you should see the power output of 1KW with 240VAC or 500W with 120VAC.
  • Page 35 NOTE: No such buffer is required if the exciter’s amplifier keying line is a dry contact closure to chassis ground. ©2006 Icom America Inc. The Icom logo is a registered trademark of Icom Inc. All other trademarks remain the property of their respective owners.
