Connecting to exciters

NOTE:
• Before connecting, confirm that the power plugs of the linear amplifier and an exciter are unplugged.
• See the exciter's instruction manual for operation.
Connecting 2 Icom exciters to [INPUT 1] and
[INPUT 2] (p. 2-5)
ANT
Icom exciter A
INPUT 1
Example: IC-7610
INPUT 2
ANT
Icom exciter B
Example: IC-7610
Connecting 1 Icom exciter to [INPUT 1] (p. 2-5)
ANT INPUT 1
Icom exciter
INPUT 2
Example: IC-7300
Connecting 1 Icom exciter to [INPUT 2] (p. 2-6)
INPUT 1
ANT INPUT 2
Icom exciter
Example: IC-7300
Connecting 1 Icom exciter to [INPUT 1] and [INPUT 2]
(p. 2-6)
ANT 1 INPUT 1
Icom exciter
ANT 2 INPUT 2
Example: IC-7610
INSTALLATION AND CONNECTIONS
Connecting 1 Icom and 1 non-Icom exciter to
[INPUT 1] and [INPUT 2] (p. 2-7)
Icom exciter
ANT 1 ～
Example: IC-7610
ANT 6
Non-Icom
exciter
Connecting 1 non-Icom exciter to [INPUT 1]
(p. 2-7)
Non-Icom
ANT 1 ～
exciter
ANT 6
Connecting 2 non-Icom exciters to [INPUT 1] and
[INPUT 2] (p. 2-8)
Non-Icom
ANT 1 ～
exciter A
ANT 6
Non-Icom
exciter B
ANT 1 ～
ANT 6
2-4
