Installation; Desk Installation; Assemble The Base Mount - StarTech.com 3M1A3SG-MONITOR-ARM User Manual

Triple monitor desk mount - crossbar design - for up to 27” monitors

Installation

Align the Screw Holes (x 4) on the top of the Top Desk

Clamp with the Screw Holes on the bottom of the Base

Mount.

Insert the Countersunk Screws (x 4) through the Top Desk

Clamp and into the bottom of the Base Mount. Use the

4mm Hex Key to tighten the Countersunk Screws (x 4).

(Figure 1)

Remove the backing from the Base Pad. (Figure 2)

For additional self-service support options and community forums, please visit: www.StarTech.com/support

Figure 1

Figure 2
