Installation; Convert The Desk Clamp To A Grommet Clamp - StarTech.com ARMDUAL Manual

Installation

WARNING! The maximum weight capacity of the Dual Monitor Arm is 27.2 kg (60 lbs).

Convert the desk clamp to a grommet clamp

The Dual Monitor Arm can be clamped to a desk or table, or mounted through a
grommet hole. The following instructions outline how to convert the default desk
clamp setup to a grommet clamp.
1. To disconnect the bottom half of the desk clamp (3), use the M4 Allen key (8) to
remove the two hex screws from the back of the desk clamp.
2. To disconnect the top half of the desk clamp (3), use the M4 Allen key (8) to remove
the four hex screws from the base of the pole.
