- Page 1 12U Rack Enclosure Actual product may vary from photos User Manual SKU#: RK1233BKM For the latest information and specifications visit www.startech.com/RK1233BKM Manual Revision: 12/07/2018...
- Page 2 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 3: Safety Statements
Säkerhetsåtgärder • Montering av kabelavslutningar får inte göras när produkten och/eller elledningarna är strömförda. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 4: Warning Statements
Förläng inte fler än en komponent från skåpet för att undvika risk. • Placera inte saker ovanpå skåpet och ställ inte skåpet ovanpå ett annat skåp. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 5 Sie niemals mehr als eine Komponente aus diesem Gehäuse aus. • Platzieren Sie keine Gegenstände auf dem Gehäuse und stapeln Sie das Gehäuse nicht auf einem anderen Gehäuse. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 6 Para evitar este risco, não expandir mais de um componente desta caixa. • Não colocar nenhum artigo nesta caixa e não empilhar a caixa em cima de outra caixa. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 7 Om dit risico te voorkomen, mag niet meer dan één component uit de behuizing steken. • Plaats geen voorwerpen op deze behuizing en stapel de behuizing niet op een andere behuizing. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 8 本製品は、 非常に重いエンクロージャです。 絶対に一人で持ち上げたり 動かしたり しないで下さい。 • 転倒注意 ！ 本製品から複数のコンポーネントが突き出した状態にしてお く とエンクロージャが転倒する恐れがあります。 転倒リスクを回避するた めに、 エンクロージャからはコンポーネントが突き出ないようにして下 さい。 • 本製品の上に何も載せないで下さい。 複数のエンクロージャを重ねて設 置しないで下さい。 • 液体物をエンクロージャに近づけないようにして下さい。 • エンクロージャ自身と中に積載する装置の総重量に耐えられるエリアに 設置して下さい。 • この製品にはアースが必要です。 アース接続をしていない状態で本製品 を使用しないでください。 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 9: Table Of Contents
Removing the Side Panels ........................15 Installing the Side Panels ........................18 Grounding the Rack ..........................18 Adjusting the Vertical Mounting Rails or Cable Management Rails ........19 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 10: Product Diagram (Rk1233Bkm)
Product Diagram (RK1233BKM) Cable Access Panel Back Door Side Panels Front Door Levelers Casters To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 11: Product Information
Open-ended Wrenches x 3 • 10 mm • 13 mm • 14 mm • Wrench x 1 • Sockets x 3 • 10 mm • 13 mm • 14 mm • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 12: Unpacking The Rack
Remove the Tie Straps from 1U Cabinet Shelf box and carefully lift the 1U Cabinet Shelf box out of the Rack through either the front or rear door. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 13 Note: Make sure that at least one person is holding the Rack in place while removing the Pallet Brackets. Carefully remove the Rack off of the Pallet and place it on a firm surface. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 14: Installation
Rack. Using a 13 mm Socket and Wrench, insert two of the Bolts through the Pallet Bracket and into the Rack. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 15: Installing The Cage Nuts
Nuts into the Rack. Use the M6 Screws to secure the Devices in place. If your Device has mounting brackets with hooks, just hook the bracket in the desired location. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 16: Removing The Front And/Or Rear Door
Notes: At least two people are required when removing or reinstalling the Side Panel from the Rack. You may have to unlock the Side Panel prior to removal. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 17 Rack, to release the side panel from the Rack Frame. Locking Latches Slowly tilt the top portion of the Side Panel away from the Rack Frame. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 18 Side Panel away from the Rack Frame. Note: The bottom of the Side Panel is hooked onto a lip on the Rack Frame. Side Panel Removed To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 19: Installing The Side Panels
Door Frame. Run the Grounding Wire under the Rack’s Frame to prevent obstructing the Rack Door from closing. Connect the Grounding Wire to an earth ground connection. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 20: Adjusting The Vertical Mounting Rails Or Cable Management Rails
Using a Phillips Head Screwdriver, remove the two M6 Screws from the Cage Nuts on the Mounting Rail. Removing the M6 Screw Slide the Mounting Rail to access the Cage Nuts. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 21 Adjustment Holes is .827” (21 mm). Insert the M6 Screws through the Mounting Rail and into the Cage Nuts. Use a Phillips Head Screwdriver to tighten the M6 Screws. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
