Install the Crossbar

Insert the Button Head Hex Screws (x 4)through the Screw
1.
Holes on the Spring Arm and into the Crossbar, Center
ensuring the correct orientation of the Crossbar, Center. Use
the 4mm Hex Key to tighten the Screws (x 4). (Figure 14)
Insert the Flat Head Screws (x 4) through the Grab Handle
2.
Screw Holes and into the Crossbar, Centre. The Grab
Handle can be mounted at two different heights depending
on which Screw Holes are used to attach it to the Crossbar,
Centre. (Figure 15)
Tighten the Flat Head Screws using the 4mm Hex Key.
3.
(Figure 15)
For additional self-service support options and community forums, please visit: www.StarTech.com/support
Figure 14
