27
- The user cannot use this connector because another
user is already using it.
- This connector has been reserved and only will be able
to use per the user that has made the reserve.
NOTE: if the user that has reserved the Charge Point is
yourself the charging session will start normally, if not,
the Charge Point will not be able to charge until the date
and time displayed have expired.
- Only for DC connectors. As the Charge Point only can
performance one DC charging session at the same time,
CCS or CHAdeMO, it could be possible to find one of
these connectors with this symbol because the other is
charging or has been reserved.
