Models Specifications
Models
Maximum AC input
current
Required power supply
capacity
Maximum output power
Output voltage range
Maximum output current
Connection
Models
Maximum AC input
current
Required power supply
capacity
Maximum output power
Output voltage range
Maximum output current
Connection
CCS
160 A
110 kVA
100 kW (@400 VDC)
DC:150 - 920 V
DC: 250 A
CCS 2
CCS CHA
160 A
110 kVA
100 kW (@400 VDC)
DC:150 - 920 V
DC: CSS 250 A / CHA
200 A
CCS 2 - JEVS G105
CCS T2C32
192 A
132 kVA
DC:100 kW (@400 VDC)
AC:22 kW
DC:150 - 920 V
AC: 400 V
DC:250 A
AC:32 A
CCS 2
Type 2 Tethered cable
CCS CHA T2S32
192 A
132 kVA
DC:100 kW (@400 VDC)
AC:22 kW
DC:150 - 920 V
AC: 400 V
DC: CSS 250 A / CHA 200 A
AC: 32 A
CCS 2 - JEVS G105
Type 2 Socket
(Lock system)
CCS T2S32
192 A
132 kVA
DC:100 kW (@400 VDC)
AC:22 kW
DC:150 - 920 V
AC: 400 V
DC:250 A
AC:32 A
CCS 2
Type 2 Socket
(Lock system)
CCS CHA T2C32
192 A
132 kVA
DC:100 kW (@400 VDC)
AC:22 kW
DC:150 - 920 V
AC: 400 V
DC: CSS 250 A / CHA
200 A
AC: 32 A
CCS 2 - JEVS G105
Type 2 Tethered cable
