How to use it ?

Tap over the screensaver, and the HMI will skip to the next screen:
Depending on the optionals chosen, the identification
methods shown in this picture can vary.
At this new screen, the Charge Point is asking for showing the identification method
the user is going to use in order to start a charge transaction, as you can see there
are three possible options.
- RFID or keyboard options will let to initiate a 'Charging session' to the user that has
the identification card, has been registered in advance or a code has been given to
type it manually in the screen.
- Paying by a debit or credit card option will let to initiate a 'Charging session' to the
user without been registered in advance.
In the lower right corner, it shows the connectors status and the charging process so
as to know the Charge Point availability.
