Watch Out!!
If your Charge Point is equipped with the 'Mechanical connector locking' accesory
at DC holders, is not possible to pull back the connectors from holders without first
unlocking it.
There are one label placed between the CHAdeMO and the CCS holders explaining
about this function. Follow the instructions given in this label and the HMI screen.
Also, there is one Led over each holder indicating the lock state:
- Red > Connector locked
- Off > Connector unlocked
08
