D
Status Beacon lights
Over each connector there is a beacon light, it indicates the state of charge in which
the socket/connector is located.
Colour Status
Green Available
Blue Charging
Cyan Booked
(OCPP 1.5)
Red Error
The connector or socket is available to start a charging
session
The connector or socket is performing a charging
session
The connector or socket has been booked by system
operator through OCPP
The Charging Station indicates that the emergency
button has been activated or some error has occurred.
Check the HMI Screen and follow the instructions
Description
06
