  • Page 1 User Manual eVolve Smart Series...
  • Page 2 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK...
  • Page 3 C O P Y R I G H T I N F O R M A T I O N This document is copyrighted, 2023 by Circontrol, S.A. All rights are reserved. Circontrol, S.A. reserves the right to make improvements to the products described in this manual at any time without notice.
  • Page 5 Here’s your guide to use and configure eVolve Smart 1 — So, hello! 2 — Glossary A - General B - Abbreviations 3 — Features 4 — How to use it? A - Before Start Charging B - Start Charging C - Stop Charging 5 —...
  • Page 6 Wallbox & Post eVolve Smart - User Manual 7— Setup Webpage A - Dashboard B - Monitor C - Historic D - Integrations E - Configuration F - Maintenance 8 — OCPP 1.6J A - Introduction B - Before starting C - Configuration 9 —...
  • Page 7 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK...
  • Page 8 Wallbox & Post eVolve Smart - User Manual This manual provides information about the usability and configuration of the Wallbox and Post eVolve Smart, which has been designed and tested to allow electric vehicle charging, specified in IEC 61851. It contains all the necessary information for safe use and help to get the best performance from it with step-by-step configuration instructions.
  • Page 9 (broken vehicle charging. plugs, caps that don’t close...). • Do not modify this unit. If • Use only Circontrol supplied modified, CIRCONTROL will spare parts. reject all responsibility and the warranty will be void.
  • Page 10 Wallbox & Post eVolve Smart - User Manual General Authorisation: Procedure to verify if an EV is allowed to charge. Charge Point (also EVSE, Electric vehicle supply equipment) Independently operated and managed part of the Charging Station that can deliver energy to ONE EV at a time.
  • Page 11 Glossary Socket-outlet: Accessory having socket-contacts designed to engage with the contacts of a plug and having terminals for the connection of cables or cords. User: Party who will specify, purchase, use and/or operate the Charging Station, or someone acting on their behalf. Abbreviations •...
  • Page 12 Wallbox & Post eVolve Smart - User Manual 1 — Hat 4 — RFID Reader 7 — Base 2 — LED Beacons 5 — Socket-outlet* 8 — Wall support 3 — Display LCD 6 — Key lock access (*) Socket-outlet may vary depending on the model...
  • Page 13 Features M A I N F E A T U R E S O F T H E U N I T Charge Point may not include elements of electrical protection. • Display: Information about • Energy metering: Integrated the status of the connectors meter built measuring...

  • Page 14: Start Charging

    Wallbox & Post eVolve Smart - User Manual Before Start Charging Before doing anything, the Charge Point’s Display shows the following sequence of messages: Start Charging 1. The first step is to show the RFID card to the reader* Once done, the Led Beacon turns Blue and the Display shows the following sequence of messages: *If the RFID card reader is disabled, charge transaction starts automatically when a vehicle is detected.
  • Page 15 How to use it? 2. Plug the cable to the vehicle, choose one available socket (in case there are more than one) and plug the cable to the Charge Point. Once done, the Display shows the following message: After the last message, the Display shows the following sequence of messages while charging:...

  • Page 16: Stop Charging

    Wallbox & Post eVolve Smart - User Manual Stop Charging 1. The first step is to show the RFID card to the reader* Once done, the Led Beacon turns Green and the Display shows the next message: After the last message, the Display shows the next sequence: *If the RFID card reader is disabled, charge transaction stops automatically when a cable is disconnected from the vehicle.
  • Page 17 2. Unplug the cable from both sides. Once done, the connector becomes available and the Display shows the following sequence of messages:...
  • Page 18 Wallbox & Post eVolve Smart - User Manual The eVolve Smart is capable of detecting the following operating errors. All of them will be displayed with a specific number of red light blinks: Wallbox - D state Error - E state Error - Proximity Error - Negative PWM voltage Error - Non-current selected Error (Dip-Switch)
  • Page 19 Status LED beacons’ errors 2 — E S T A T E E R R O R This means that there has occurred a communication error between the EV and the Charge Point. If this is the case, the status LED light bar flashes in a sequence of two blinks.
  • Page 20 Wallbox & Post eVolve Smart - User Manual 6 — W E L D E D C O N T A C T E R R O R An internal short-circuit has been detected. In this case, the status LED light bar flashes in a sequence of seven blinks.
  • Page 21 1 0 — M A X I M U M T E M P E R A T U R E E R R O R When the Charge Point’s temperature is above a certain value, the status LED light bar flashes in a sequence of eleven blinks. If this is the case, the Charge Point will not be operating, temperature is too high to charge, so you will have to wait until the operating temperature is reached.

  • Page 22: What's Needed

    Ethernet communication port allocated in the main controller device. What’s needed Before proceeding with the configuration, make sure all the following is ready: Computer running Microsoft Windows, at least Windows XP . UTP Cable IPSetup.exe (Software provided by Circontrol)

  • Page 23: How To Configure It

    How to configure it? Connection Charge Point is delivered with default network setting of “DHCP enabled”. It means that the charge station will try to obtain an IP address from a DHCP server available on the network. Connecting a PC directly with the Charge Point needs to be done with static IP address.
  • Page 24 Wallbox & Post eVolve Smart - User Manual • Enter the desired IP Address • Click on “Configure” Once done, the Setup Webpage is opened automatically on the default web browser.
  • Page 25 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK...
  • Page 26 Wallbox & Post eVolve Smart - User Manual Setup webpage allows managing network setup, upgrading devices and other options. To access the setup web page, open a web browser and enter the IP address previously configured. In the main page, ‘Info’ button shows some relevant information about the Charge Point like the serial number or firmware version.

  • Page 27: Setup Webpage

    Setup Webpage Dashboard Overview As a relevant information, Dashboard shows different states of: • Communications • Charge Point • Active Integration • Last charges...
  • Page 28 Wallbox & Post eVolve Smart - User Manual Communications The information shown in this section is basically relative to the state of the Ethernet, Modem and Wi-Fi communications. Charge Point The information shown in this section is basically relative to the state of the Charge Point.
  • Page 29 Last Charges (Last 2 days) The information shown in this section is basically relative to the charges of the last 2 day. Relevant information will be displayed for each charge. Monitor This section provides the status of the Charge Point, the type of connectors it has and the availability of them.
  • Page 30 Wallbox & Post eVolve Smart - User Manual Historic This section provides relevant information on each charge made up to the 7 last days. It can be checked date and hour of begin and end of a charge transaction, energy charged, alias of the user and type of charge used. It is also possible to export this information to a ‘CSV’...
  • Page 31 Configuration Identification method This section allows the user to select whether the Charge Point needs authorisation via RFID or not. Plugs This section provides the current limit of each plug. This current limit can be modified by just pressing the desired plug and the ‘Edit’ button. Then, write the desired value.
  • Page 32 Wallbox & Post eVolve Smart - User Manual Charge In the ‘Power Balance’ section, it can be enabled the status of the Charge Point. Two different options can be allowed after enable the status: • Shared Power: it indicates the power available to divide between the connected vehicles.
  • Page 33 Communications In the General section, Hostname can be modified. In the Ethernet section, if DHCP is enabled, an automatic IP address will be assigned. Otherwise, you must manually configure the IP address.
  • Page 34 Wallbox & Post eVolve Smart - User Manual Value Description DHCP Client Client ID associated to the DHCP server (if enabled). IP Address IP Address assigned to the Charge Point. Default Gateway Gateway of the network. Subnet Mask Mask of the network. Primary DNS Server IP address of the Primary DNS Server.
  • Page 35 Value Description Internal modem Enable/Disable Modem communication. Access Point Name (consult the SIM card provider). Credentials assigned to the APN (consult SIM provider). User/Password Note: if credentials are not neede, insert “1234” on both fields. Consult the SIM card network provider for the PIN. Reset on ping Enable/disable to reset the Modem when there is a ping failure.
  • Page 36 Wallbox & Post eVolve Smart - User Manual In the Wi-Fi section can be configured multiples settings such as the Wi-Fi Network where the equipment is connected and the IP address to access the Charge Point when connected to the Wi-Fi. Value Description SSID...
  • Page 37 In the Proxy section, a server, with credentials and exceptions, can be configured as an intermediary between the connections with the Charge Point. Value Description Server IP of the proxy server. Port Port of the proxy server. Username Credentials of the proxy server. Password/Repeat password Exceptions Devices to avoid going through the proxy server.
  • Page 38 Wallbox & Post eVolve Smart - User Manual In the Status section, the user can see the current state of Ethernet, Modem and Wi-Fi, and more relevant information about each one. The following diagram shows an approximated range of signal strength that can be obtained depending on the location of the Charge Point.
  • Page 39 Security This section provides basic configuration of the security parameters, avoiding unauthorised access to the Setup Web page. Value Description Enabled: information transferred between Charge Point and laptop is strictly encrypted. Allow only secure connections Disabled: not possible to assure secure connections between Charge Point and laptop.

  • Page 40: Maintenance

    Wallbox & Post eVolve Smart - User Manual Maintenance Device Status This section provides the status of some devices of the Charge Point. Updates This section is related to the firmware and configuration updates. To upgrate to a new version, it is necessary to upload the file. There is also a brief summary with relevant information.
  • Page 41 To obtain the latest firmware version and configuration file please contact CIRCONTROL Post Sales Department. More information in ‘Need help?’ chapter. Diagnostics The logs shown in this section are automatically produced by the Charge Point. It is a detailed list of the charging sessions, system performance or user activities.
  • Page 42 Wallbox & Post eVolve Smart - User Manual System Status The information shown in this section is regard to the drivers that the Charge Point needs in order to recognize the different devices inside the Charge Point, such as the meters, the RFID reader, etc. The information shown below, about the repository sources, is basically related to the internal behavior of the Charge Point.
  • Page 43 Advanced This section allows setting the time and region time for the Charge Point. Also, it offers the possibility to reset the Charge Point. Value Description Select the regional time for the Charge Point Time zone according to the locaion. Device time Current date and time of the Charge Point.
  • Page 44 Central System with any Charge Point, regardless of the vendor. Follow and check the following steps in order to configure and to ensure the correct function of OCPP 1.6J in the Circontrol Charge Points.

  • Page 45: Before Starting

    OCPP 1.6J Before starting Go to the Integrations > ‘General’ tab Charge Point supports different versions of OCPP but only one can be enabled at the same time. At the moment, only OCPP 1.6J can be selected. Choose the option selected under ‘Available integrations’ according to your backend policies as shown in the picture below.
  • Page 46 Wallbox & Post eVolve Smart - User Manual Value Description Charge Point ID Charge Point identifier. URL address of the central system. Connection URL Basic Set an authentication if required, being the options ‘Enabled’ and Authentication ‘Disabled’. Introduce CS-Password if required. CS-Password If ‘None’...
  • Page 47 Value Description Use OCCP time synchronization Enabled/Disabled Partial: sends partial energy consumption while vehicle is charging. Energy for metervalues Total: sends the actual count of the total accumulated energy meter. Send metervalues only while Enabled/Disabled charging Discard middle measures in Enabled/Disabled StopTransaction OCPP Smart Charging...
  • Page 48 Wallbox & Post eVolve Smart - User Manual Go to the Integrations > ‘Settings’ > ‘Analysis’ tab In this section, it can be set the capture level of the logs. It can also be enabled the option to keep the logs into local storage. Value Description Keep logs into local storage...
  • Page 49 Go to the Integrations > ‘SSL Certificates’ tab For WSS connections, is needed a Central System certificate. Upload it in this section. To obtain the latest certificates, please contact Central System you are working with. Settings are always stored even when the Charge Point is powered off or even the integration is disabled/stopped.
  • Page 50 Wallbox & Post eVolve Smart - User Manual Go to the Integrations > ‘Configuration Keys’ tab The Core section provides some parameters related to the Setup Webpage that can be enabled/disabled or modified according to the user’s preferences.
  • Page 51 Value Description Enabled: during offline period locally-authorized identifiers are allowed to start charging. Local authorisation off-line Disabled: during offline period locally-authorized identifiers are NOT allowed to start charging. Enabled: during offline period, unknown identifi- ers are allowed to start charging. Allow offline Tx for unknown ID Disabled: during offline period, unknow identifi- ers are NOT allowed to start charging.
  • Page 52 Wallbox & Post eVolve Smart - User Manual Value Description Heartbeat send interval (in seconds) for the Heartbeat interval backend system. *NOTE: setting this value to 0 disables the Heartbeat. Number of seconds between MeterValue during an ongoing charge transaction. Metervalues sample interval *NOTE: setting this value to 0 disables the MeterValue.
  • Page 53 Go to the Integrations > ‘Configuration Keys’ > ‘Advanced’ tab As a relevant information, this section shows: • Local authorisation list • Authorisation cache Both options can be enabled or disabled and it is possible to show a list of each one. Go to the Integrations >...
  • Page 54 Point in order to monitor the real-time status. The main way to connect is using the CirCarLife client software (Supplied by Circontrol PS-Support staff) or you can download it from Circontrol Expert Area Webpage. NOTE: Java software needs to be installed on the computer in order to run the client software, please, download last version from: www.java.com...
  • Page 55 Monitoring...
  • Page 56 Wallbox & Post eVolve Smart - User Manual Post DATA GENERAL SPECIFICATIONS Light beacon RGB Colour indicator Enclosure rating IP54 / IK10 Enclosure material Aluminium & ABS Enclosure door Frontal key locked door Net weight 55 Kg Dimensions (W x H x D) 450 x 1550 x 290 mm Socket Type 2 + Locking System...

  • Page 57: Technical Data

    Technical Data GENERAL DATA Display LCD Multi-language ISO/IEC 14443 A&B RFID reader Felica ISO/IEC 15693/ICODE Meter MID Class 1 - EN50470-1/3 Ethernet 10/100BaseTX (TCP-IP) Wi-Fi Wi-Fi 2.4 GHz (IEEE 802.11 b/g/n) Cellular (optional) Embedded modem 4G LTE/3G/GPRS Interface protocol OCPP 1.6J / OCPP 2.0.1 Ready Charging mode Mode 3 MINIMUM...
  • Page 58 Wallbox & Post eVolve Smart - User Manual Wallbox DATA GENERAL SPECIFICATIONS Light beacon RGB Colour indicator Enclosure rating IP54 / IK10 Enclosure material Aluminium & ABS Enclosure door Frontal key locked door Net weight 55 Kg Dimensions (W x H x D) 222 x 382 x 928 mm Socket Type 2 + Locking System...

  • Page 59: General Data

    GENERAL DATA Display LCD Multi-language ISO/IEC 14443 A&B RFID reader Felica ISO/IEC 15693/ICODE Meter MID Class 1 - EN50470-1/3 Ethernet 10/100BaseTX (TCP-IP) Wi-Fi Wi-Fi 2.4 GHz (IEEE 802.11 b/g/n) Cellular (optional) Embedded modem 4G LTE/3G/GPRS Interface protocol OCPP 1.6J / OCPP 2.0.1 Ready Charging mode Mode 3 MINIMUM...
  • Page 60 Wallbox & Post eVolve Smart - User Manual...

  • Page 61: Need Help

    Need help? In case of any query or if further information is required, please contact our Post-Sales Department. support@circontrol.com www.circontrol.com (+34) 937 362 940 (+34) 937 362 941...
  • Page 62 CIRCONTROL eVOLVE SMART SERIES USER MANUAL A comprehensive guide on how to use and configure your Charge Point. v2.5 - 16 October 2023 CIRCONTROL S.A. - ALL RIGHTS RESERVED...
