SET BACNET ACCESS:

By Pressing the "Set BACnet Access
14).
The window is divided in two parts,
the "BACnet in Read" that contains
the BACnet objects readable by a
BACnet master (the PROFIBUS data
associated to these objects are the
data that the slaves PROFIBUS sends
to the converter); and "BACnet in
Write" that contains the
objects writeable by a BACnet master
(the PROFIBUS data associated to
these objects are the data that the
the converter sends to
PROFIBUS).
The meaning of the fields in the
window are the follows:
In the field "Data Type" is
possible to select the BACnet
object data type;
In the field "Eng. Unit", with
double click the window "Select
the BACnet Engineering Unit"
appears (Fig. 15);
In the field "Position"
possible to select the position
where take/save the data from
the bytes of PROFIBUS;
The field "Start Bit" is used for
the "Binary In" and "Binary Out" BACnet objects;
The field "Length" is used for all the others BACnet objects.
ADFweb.com S.r.l.
" button from the "PROFIBUS Network" window (Fig. 4) the window "Set BACnet Access" appears (Fig.
BACnet
slaves
is
Figure 14: "BACnet Set Access" window
