SET BACNET ACCESS:

By Pressing the "Set BACnet
The window is divided in two parts, the
Read" that contains the BACnet objects readable by
a BACnet Master (the MQTT messages subscribed);
and "BACnet in Write" that contains the BACnet
objects writeable by a BACnet Master (the MQTT
messages published).
The meaning of the fields in the window are the
follows:
In the field "Data Type" is possible to select
the BACnet object data type;
In the field "Eng. Unit", with double click the
window "Select the BACnet Engineering Unit"
appears (Fig. 6);
In the field "Position" is possible to select
the position where take/save the data from a
6000 bytes array;
The field "Start Bit" is used for the "Binary
In" and "Binary Out" BACnet objects;
The field "Length" is used for all the others
BACnet objects;
In the field "Mnemonic" a description of the
object is defined.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Access" button from the main window for SW67938 (Fig. 2) the window "BACnet Set Access" appears (Fig. 5).
"BACnet in
Figure 10: "BACnet Set Access" window
