PROFIBUS NETWORK:

By pressing the "PROFIBUS
appears.
In this window is possible to:
Modify the PROFIBUS Master Options
Add a PROFIBUS Slave in the Network of the Master
Modify a PROFIBUS Slave in the Network
Remove a PROFIBUS Slave from the Network
("Remove Slave PROFIBUS");
Define the BACnet objects related to a slave
PROFIBUS ("Set BACnet
Figure 4: "PROFIBUS Network" window
ADFweb.com S.r.l.
Network" button from the main window for SW67675 (Fig. 2) the window "PROFIBUS Network" (Fig. 4)
("Master PROFIBUS
("Add Slave
("Modify Slave
Access").
User Manual BACnet slave / PROFIBUS master - Converter
Document code: MN67675_ENG
Options");
PROFIBUS");
PROFIBUS");
