If selected "BACnet MS/TP" or "BACnet PTP" the means of the fields for "BACnet" are:
In the field "Baudrate" it is possible to select the baudrate of the BACnet line (1200, 2400,
4800, 9600, 19200, 38400, 57600, 115200);
In the field "Parity" it is possible to select the parity of the line (None, Odd, Even);
In the field "BACnet Device
node (maximum 17 characters);
In the field "MAC Address" is possible to define the MAC of BACnet node (from 0 to 254);
The means of the fields for the "Ethernet Update" section are:
In the fields "IP ADDRESS" insert the IP address that you want to give to the Converter;
In the fields "SUBNET
In the fields "GATEWAY" insert the default gateway that you want to use. This feature can
be enabled or disabled pressing the Check Box field. This feature is used for going out of the
net.
These information are used for programming the Converter.
ADFweb.com S.r.l.
Name" is possible to insert the name to give to the BACnet
Mask" insert the SubNet Mask;
