M S :
ODULE ELECTION
The section "Module Selection" is used to select
which Modules are present in the Slave (Fig. 7).
In this section is possible to:
Check the list of the Modules selected ("Select
Modules") (Fig. 7, point (1)) and the list of
Modules Available in GSD file ("Available
Modules") (Fig. 7, point (7));
Add a Module from the list of GSD file (Fig. 7,
point (6));
Remove a Module from selected list (Fig. 7,
point (5));
Add all Modules present in the GSD file (Fig.
7, point (4));
Remove all Modules from selected list (Fig. 7,
point (3));
Insert a Module not present in the GSD file
("Manual Module") (Fig. 7 point (2)). For
more info see the section "Manual Module"
below.
Figure 7: "PROFIBUS Device – Module Selection"
window
