Industrial Electronic Devices
User Manual
Revision 1.000
English
PROFINET Slave / Ethernet - Converter
(Order Code: HD67659-A1)
for Website information:
http://www.adfweb.com/?Product=HD67659
for Price information:
http://www.adfweb.com/?Price=HD67659-A1
Benefits and Main Features:
Triple electrical isolation
Two Ethernet ports
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual PROFINET Slave / Ethernet - Converter
Document code: MN67659_ENG
For others PROFINET slave converters, see also the following links:
PROFINET from/to ...
www.adfweb.com?Product=HD67078
www.adfweb.com?Product=HD67090
www.adfweb.com?Product=HD67178
www.adfweb.com?Product=HD67600
www.adfweb.com?Product=HD67601
www.adfweb.com?Product=HD67602
www.adfweb.com?Product=HD67603
www.adfweb.com?Product=HD67604
www.adfweb.com?Product=HD67605
www.adfweb.com?Product=HD67606
www.adfweb.com?Product=HD67607
www.adfweb.com?Product=HD67608
www.adfweb.com?Product=HD67609
www.adfweb.com?Product=HD67610
www.adfweb.com?Product=HD67611
www.adfweb.com?Product=HD67612
www.adfweb.com?Product=HD67613
www.adfweb.com?Product=HD67614
www.adfweb.com?Product=HD67615
www.adfweb.com?Product=HD67660
www.adfweb.com?Product=HD67679
www.adfweb.com?Product=HD67719
www.adfweb.com?Product=HD67752
www.adfweb.com?Product=HD67778
www.adfweb.com?Product=HD67818
www.adfweb.com?Product=HD67848
www.adfweb.com?Product=HD67912
www.adfweb.com?Product=HD67952
www.adfweb.com?Product=HD67B22
www.adfweb.com?Product=HD67B46
www.adfweb.com?Product=HD67C77
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.000
Page 1 of 26
(M-Bus)
(M-Bus Wireless)
(SNMP Manager)
(NMEA 2000)
(Serial)
(Modbus Master)
(Modbus Slave)
(PROFIBUS Master)
(PROFIBUS Slave)
(CAN)
(CANopen)
(DeviceNet Master)
(DeviceNet Slave)
(J1939)
(Modbus TCP Master)
(Modbus TCP Slave)
(SNMP Agent)
(DMX)
(NMEA 0183)
(EtherNet/IP)
(BACnet Slave)
(BACnet Master)
(IEC 61850 Server)
(IEC 61850 Client)
(KNX)
(DALI)
(HART Master)
(MQTT)
(OPC UA Client)
(OPC UA Server)
(EnOcean)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADF Web HD67659-A1
Summary of Contents for ADF Web HD67659-A1
- Page 1 (DeviceNet Slave) www.adfweb.com?Product=HD67610 (J1939) www.adfweb.com?Product=HD67611 (Modbus TCP Master) PROFINET Slave / Ethernet - Converter www.adfweb.com?Product=HD67612 (Modbus TCP Slave) www.adfweb.com?Product=HD67613 (SNMP Agent) (Order Code: HD67659-A1) www.adfweb.com?Product=HD67614 (DMX) www.adfweb.com?Product=HD67615 (NMEA 0183) for Website information: www.adfweb.com?Product=HD67660 (EtherNet/IP) http://www.adfweb.com/?Product=HD67659 www.adfweb.com?Product=HD67679 (BACnet Slave) www.adfweb.com?Product=HD67719 (BACnet Master) www.adfweb.com?Product=HD67752...
-
Page 2: Updated Documentation
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 2 of 26 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 3 of 26 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 4 of 26 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 5 of 26 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67659-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 6 Page 6 of 26 Industrial Electronic Devices CHARACTERISTICS: The HD67659-A1 is a PROFINET Slave / Ethernet Converter. It allows the following characteristics: Up to 500 bytes in reading and 500 bytes in writing on Ethernet side; Two-directional information between Ethernet and PROFINET;...
-
Page 7: Power Supply
POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD67659-A1 Consumption at 24V DC: Device W/VA HD67659-A1 Caution: Not reverse the polarity power HD67659-A1 ADFweb.com Srl –... -
Page 8: Function Modes
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 8 of 26 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch B’: The first, with Dip1 in Off position (factory setting), is used for the normal working of the device. The second, with Dip1 in On position, is used for upload the Project/Firmware. - Page 9 User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 9 of 26 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered...
- Page 10 ETHERNET: The Ethernet connection must be made using Connector3 or Connector4 of HD67659-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.
- Page 11 User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 11 of 26 Industrial Electronic Devices USE OF COMPOSITOR SW67659: To configure the Converter, use the available software that runs with Windows called SW67659. It is downloadable on the site www.adfweb.com and its operation is described in this document.
-
Page 12: New Configuration / Open Configuration
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 12 of 26 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “PROFINET Slave / Ethernet - Converter”... -
Page 13: Software Options
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 13 of 26 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. -
Page 14: Set Communication
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 14 of 26 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, PROFINET and Ethernet. By Pressing the “Set Communication” button from the main window for SW67659 (Fig. 2) the window “Set Communication”... - Page 15 User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 15 of 26 Industrial Electronic Devices PROFINET XML: By pressing the “PROFINET XML” button it is possible to save the xml file for the PROFINET side. With this feature you can save the configuration of the converter of the PROFINET side.
-
Page 16: Update Device
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 16 of 26 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn off the Device;... - Page 17 User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 17 of 26 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67659 device.
-
Page 18: Ethernet Protocol
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 18 of 26 Industrial Electronic Devices ETHERNET PROTOCOL: In order to read and write the data from PROFINET side, it is enough to send some simple commands over TCP or UDP. Reading data from HD67659 (PROFINET ... - Page 19 User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 19 of 26 Industrial Electronic Devices Writing data to HD67659 (Ethernet PROFINET) Request: Byte Number Description ‘W’ (0x57) ‘.’ (0x2E) 3÷5 Starting output byte to write (decimal) ‘...
-
Page 20: Mechanical Dimensions
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 20 of 26 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 6: Mechanical dimensions scheme for HD67659-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 21: Ordering Informations
Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67659: PROFINET Slave / Ethernet – Converter Order Code: HD67659-A1 PROFINET Slave / Ethernet - Converter ACCESSORIES: Order Code: AC34011 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC Order Code: AC34012 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –... -
Page 22: Plc Configuration
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 22 of 26 Industrial Electronic Devices PLC CONFIGURATION: The configuration and commissioning of the PROFINET Converter as described on the following pages was accomplished with the help of the TIA Portal software of Siemens. - Page 23 User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 23 of 26 Industrial Electronic Devices 2) Import the module in the network; connect the device to the PLC network and edit the parameters of IP, station name etc. ADFweb.com Srl –...
- Page 24 User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 24 of 26 Industrial Electronic Devices 3) Load the configuration into the PLC. ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 25: Other Regulations And Standards
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 25 of 26 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 26: Warranties And Technical Support
User Manual PROFINET Slave / Ethernet - Converter Document code: MN67659_ENG Revision 1.000 Page 26 of 26 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
