Connector Summary

Designator Connector
P1 TX2/TX2i Module Connector
P2 HDMI
P4 Expansion IO Header
P5 Gigabit Ethernet
P6 Micro SD Card Slot
P7 USB 3.0
P8 USB OTG
P9 Power Input
Switch Summary & Locations
Designator Function
S1 Fan / Power Control Power Start-up Control, FAN PWM / Always ON Control
SW1 Power Button
SW2 Reset Button
SW3 Recovery
Document: CTIM-00471
Revision: 0.14
NVIDIA Jetson TX2/TX2i/TX1 Module Board-to-Board
Connector
HDMI 2.0 Maximum: 6Gbps, 24bpp, 4096x2160@60Hz
Expansion IO Header Interfacing to all Misc IO
Gigabit Ethernet 10/100/1000 BASE-T Connection
Micro SD Card Slot (4-bit Data, Support for SD 4.0)
USB 3.0 Type-A Host Connection
USB OTG (Host Mode and Client Mode capable)
DC Power Input (+9V to +14V)
Power Button, Press to Power ON or OFF
Reset Button, Press to initiate Reset Sequence
Use to initiate a recovery mode, and flash new image via USB OTG
