Omron CJ - INSTRUCTIONS REFERENCE MANUAL 07-2009 Reference Manual page 92

Instruction Symbol/Operand
Mnemonic
Code
DOUBLE SHIFT
NSLL(582)
N-BITS LEFT
NSLL
@NSLL
582
D: Shift word
C: Control word
SHIFT N-BITS
NASR(581)
RIGHT
NASR
@NASR
581
D: Shift word
C: Control word
DOUBLE SHIFT
NSRL(583)
N-BITS RIGHT
NSRL
@NSRL
583
D: Shift word
C: Control word
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Shifts the specified 32 bits of word data to the left by the specified
number of bits.
D
C
Lost
Shifts the specified 16 bits of word data to the right by the specified
number of bits.
D
C
Contents of "a" or
"0" shifted in
Shifts the specified 32 bits of word data to the right by the specified
number of bits.
D
C
Contents of
"a" or "0"
shifted in
N bits
2. Summary of Instructions
Function
Shift n-bits
Contents of
"a" or "0"
shifted in
N bits
N bits
Shift n-bits
Location Page
Execution
condition
Output 324
Required
Output 327
Required
Lost
Output 327
Required
Lost
55
2
