PRV2
Instruction Mnemonic
COUNTER
PRV2
FREQUENCY CONVERT
Symbol
Applicable Program Areas
Function block
Area
definitions
Usage OK
Operands
Operand
C1 Control data
C2 Pulses per revolution
D First destination word
C1: Control data
C1
0 *0 hex
0001 hex
C1 0
(When Conversion Type is "Frequency to speed")
Pulse Frequency Calculation Method
0 hex: Standard calculation method
1 hex: High-frequency calculation method, 10-ms sampling (See note.)
2 hex: High-frequency calculation method, 100-ms sampling (See note.)
3 hex: High-frequency calculation method, 1,000-ms sampling (See note.)
(When Conversion Type is "Frequency to speed")
Speed Unit
0 hex: r/min
1 hex: r/s (See note.)
2 hex: r/h (See note.)
Note Supported by CJM1 CPU Unit Ver. 3.0 or later only.
C2: Pulses per Revolution
Specifies the number of pulses per revolution (0001 to FFFF hex).
D: First Destination Word
15
D Conversion result (Rightmost 4 digits)
D+1 Conversion result (Leftmost 4 digits)
728
Function
Variations
code
@PRV2 883
Block program areas Step program areas
OK OK
Description
Converts frequency to rotation speed.
(The second digit of C ( ) specifies the units and the third digit (*) specifies the frequency calculation method.)
Converts counter PV to total number of revolutions.
Conversion Type
0 hex: Frequency to speed
1 hex: Counter PV to total revolutions
0
Function
PRV2(883) reads the pulse frequency input from a high-speed
counter and either converts the frequency to a rotational speed or
converts the counter PV to the total number of revolutions. The
result is output to the destination words as 8-digit hexadecimal.
PRV2
PRV2(883)
C1 C1: Control data
C2: Pulses per revolution
C2
D: First destination word
D
Subroutines Interrupt tasks
OK
PRV2(883) function
CS/CJ/NSJ Series Instructions Reference Manual (W474)
SFC action or transition
programs
OK OK
Data type Size
WORD 1
UINT 1
UDINT 2
