2. Summary of Instructions
Instruction Symbol/Operand
Mnemonic
Code
DOUBLE TAN-
GENT
TAND(853)
TAND
@TAND
853
S: 1st source
word
R: 1st result word
DOUBLE ARC
SINE ASIND(854)
ASIND
@ASIND
854
S: 1st source
word
R: 1st result word
DOUBLE ARC
COSINE ACOSD(855)
ACOSD
@ACOSD
855
S: 1st source
word
R: 1st result word
DOUBLE ARC
TANGENT ATAND(856)
ATAND
@ATAND
856
S: 1st source
word
R: 1st result word
DOUBLE
SQUARE ROOT SQRTD(857)
SQRTD
@SQRTD
857
S: 1st source
word
R: 1st result word
DOUBLE EXPO-
NENT EXPD(858)
EXPD
@EXPD
858
S: 1st source
word
R: 1st result word
DOUBLE LOGA-
RITHM LOGD(859)
LOGD
@LOGD
859
S: 1st source
word
R: 1st result word
80
Calculates the tangent of the angle (radians) in the specified double-preci-
sion floating-point data (64 bits) and outputs the result to the result words.
S
R
Calculates the angle (in radians) from the sine value in the specified dou-
ble-precision floating-point data (64 bits) and outputs the result to the
result words. (The arc sine function is the inverse of the sine function; it
S
returns the angle that produces a given sine value between -1 and 1.)
R
Calculates the angle (in radians) from the cosine value in the specified
double-precision floating-point data (64 bits) and outputs the result to the
result words. (The arc cosine function is the inverse of the cosine function;
S
it returns the angle that produces a given cosine value between -1 and 1.)
R
Calculates the angle (in radians) from the tangent value in the specified
double-precision floating-point data (64 bits) and outputs the result to the
result words. (The arc tangent function is the inverse of the tangent func-
S
tion; it returns the angle that produces a given tangent value.)
R
Calculates the square root of the specified double-precision floating-point
data (64 bits) and outputs the result to the result words.
S
R
Calculates the natural (base e) exponential of the specified double-preci-
sion floating-point data (64 bits) and outputs the result to the result words.
S
R
Calculates the natural (base e) logarithm of the specified double-precision
floating-point data (64 bits) and outputs the result to the result words.
S
R
Function
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Location Page
Execution
condition
Output 524
Required
Output 527
Required
Output 527
Required
Output 527
Required
Output 530
Required
Output 532
Required
Output 534
Required
