Omron CJ - INSTRUCTIONS REFERENCE MANUAL 07-2009 Reference Manual page 79

2. Summary of Instructions
Instruction Symbol/Operand
Mnemonic
Code
HUNDREDTH-MS
TMUH(554)
TIMER (CJ1-H-R
and CJ2 only)
TMUH
554
N: Timer number
(BCD)
S: Set value
TMUHX
TMUHX(557)
557
(BCD)
N: Timer number
S: Set value
ACCUMULATIVE Timer
TTIM(087)
input
TIMER
TTIM
087
(BCD)
Reset
input
TTIMX
N: Timer number
555
(Binary) S: Set value
(CJ2, CS1-H,
CJ1-H, CJ1M, or
Timer
CS1D only) TTIMX(555)
input
Reset
input
N: Timer number
S: Set value
LONG TIMER
TIML(542)
TIML
542
(BCD)
TIMLX
553
(Binary) D1: Completion
(CJ2, CS1-H,
Flag
CJ1-H, CJ1M, or
D2: PV word
CS1D only)
S: SV word
TIMLX(553)
D1: Completion
Flag
D2: PV word
S: SV word
42
TMUH(554)/TMUHX(557) operates an decrementing timer with units of
0.01-s. The setting range for the set value (SV) is 0 to 0.0999 s for BCD
and 0 to 0.65535 s for binary (decimal or hexadecimal).
N
S
ON
Timer input
OFF
Timer PV
0
Completion
ON
N
Flag OFF
S
Timer Input Turns OFF before Completion Flag Turns ON
ON
Timer input
OFF
SV
Timer PV
0
Completion
ON
Flag
OFF
Note: The timer's present value cannot be accessed for a HUN-
DREDTH-MS TIMER instruction.
TTIM(087)/TTIMX(555) operates an incrementing timer with units of
0.1-s. The setting range for the set value (SV) is 0 to 999.9 s for
N
BCD and 0 to 6,553.5 s for binary (decimal or hexadecimal).
S
Timer input
SV
Timer PV
N
S
Completion
Flag
Reset input
TIML(542)/TIMLX(553) operates a decrementing timer with units of
0.1-s that can time up to approx. 115 days for BCD and 49,710 days
D1 for binary (decimal or hexadecimal).
Timer input
D2
S
Timer PV
Completion Flag
(Bit 00 of D1)
D1
D2
S
Function
SV
Timing resumes.
PV maintained.
SV
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Location Page
Execution
condition
Output 227
Required
Output 230
Required
Output 233
Required
