Omron CJ - INSTRUCTIONS REFERENCE MANUAL 07-2009 Reference Manual page 72

Instruction Symbol/Operand
Mnemonic
Code
SINGLE BIT
RESET (CJ2, RSTB(533)
CS1-H, CJ1-H,
CJ1M, or CS1D
only)
RSTB
@RSTB
D: Word address
*1
!RSTB
N: Bit number
*1
!@RSTB
SINGLE BIT
OUTB(534)
OUTPUT (CJ2,
CS1-H, CJ1-H,
CJ1M, or CS1D
only)
OUTB
@OUTB
D: Word address
*1
!OUTB
N: Bit number
CS/CJ/NSJ Series Instructions Reference Manual (W474)
RSTB(533) turns OFF the specified bit in the specified word when the
execution condition is ON.
Unlike the RSET instruction, RSTB(533) can be used to reset a bit in a
D
DM or EM word.
N
OUTB(534) outputs the result (execution condition) of the logical pro-
cessing to the specified bit.
Unlike the OUT instruction, OUTB(534) can be used to control a bit in a
D
DM or EM word.
N
2. Summary of Instructions
Function Location Page
Execution
condition
Output 170
Required
Output 172
Required
2
35
