Instruction Symbol/Operand
Mnemonic
Code
SINGLE WORD
DIST(080)
DISTRIBUTE
DIST
@DIST
080
S: Source word
Bs: Destination
base address
Of: Offset
DATA COLLECT
COLL(081)
COLL
@COLL
081
Bs: Source base
address
Of: Offset
D: Destination
word
MOVE TO REGIS-
MOVR(560)
TER
MOVR
@MOVR
560
S: Source
(desired word or
bit)
D: Destination
(Index Register)
MOVE TIMER/
MOVRW(561)
COUNTER PV TO
REGISTER
MOVRW
@MOVRW
561
S: Source
(desired TC
number)
D: Destination
(Index Register)
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Transfers the source word to a destination word calculated by adding
an offset value to the base address.
S
S
Bs
Of
Transfers the source word (calculated by adding an offset value to the
base address) to the destination word.
Bs
Bs
Of
D
Bs+n
Sets the internal I/O memory address of the specified word, bit, or
timer/counter Completion Flag in the specified Index Register. (Use
MOVRW(561) to set the internal I/O memory address of a
S
timer/counter PV in an Index Register.)
D
Sets the internal I/O memory address of the specified timer or
counter's PV in the specified Index Register. (Use MOVR(560) to set
the internal I/O memory address of a word, bit, or timer/counter
S
Completion Flag in an Index Register.)
D
Timer/counter PV only
2. Summary of Instructions
Function
B s
Of
Bs+n
Of
I/O memory address of S
Index Register
I/O memory address of S
Index Register
Location Page
Execution
condition
Output 292
Required
Output 294
Required
2
Output 296
Required
Output 296
Required
