2. Summary of Instructions
2-2-34 Model Conversion Instructions (CPU Unit Ver. 3.0 or Later and
CJ2 CPU Units Only)
Instruction Symbol/Operand
Mnemonic
Code
BLOCK
TRANSFER
XFERC(565)
XFERC
@XFERC
565
N: Number of
words
S: 1st source
word
D: 1st destination
word
SINGLE WORD
DISTC(566)
DISTRIBUTE
DISTC
@DISTC
566
S: Source word
Bs: Destination
base address
Of: Offset
DATA COLLECT
COLLC(567)
COLLC
@COLLC
567
Bs: Source base
address
Of: Offset
D: Destination
word
MOVE BIT
MOVBC(568)
MOVBC
@MOVBC
568
S: Source word or
data
C: Control word
D: Destination
word
BIT COUNTER
BCNTC(621)
BCNTC
@BCNTC
621
N: Number of
words (BCD)
S: 1st source
word
R: Result word
122
Transfers the specified number of consecutive words.
N
S
to
D
S+(N−1)
Transfers the source word to a destination word calculated by adding
an offset value to the base address. Can also write to a stack (Stack
S
Push Operation).
S
Bs
Of
Transfers the source word (calculated by adding an offset value to the
base address) to the destination word. Can also read data from a
Bs
stack in FIFO or LIFO order (Stack Read Operation).
Of
Bs
D
Bs+n
Transfers the specified bit.
S
C
D
Counts the total number of ON bits in the specified word(s).
N
S
R
S+(N 1)
Function
N words
−
D+(N 1)
B s
Of
Bs+n
Of
N words
Counts the number
of ON bits.
to
BCD result
R
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Location Page
Execution
condition
Output 1071
Required
to
Output 1073
Required
Output 1076
Required
Output 1079
Required
Output 1081
Required
