Omron CJ - INSTRUCTIONS REFERENCE MANUAL 07-2009 Reference Manual page 740

MSKS
Instruction
SET INTERRUPT MASK
Symbol
Applicable Program Areas
Function block
Area
definitions
Usage OK
Operands
Operand
N Interrupt identifier
C Control data
(1) Disabling/Enabling an I/O Interrupt Task's Interrupt Input
Operand
N
Inputs to a CS1W-INT01/CJ1W-INT01
Interrupt Input Unit (16 inputs/Unit)
Inputs to a C200HS-INT01 Interrupt Input
Unit (8 inputs/Unit)
Inputs to a CJ1M CPU Unit's Built-in Inputs
(4 inputs/Unit)
C
Inputs to a CS1W-INT01/CJ1W-INT01
Interrupt Input Unit (16 inputs/Unit)
Inputs to a C200HS-INT01 Interrupt Input
Unit (8 inputs/Unit)
Inputs to a CJ1M CPU Unit's Built-in Inputs
(4 inputs/Unit)
(2) Specifying Up/Down Differentiation of an Interrupt Input
(CS1W-INT01, CJ1W-INT01, and CJ1M CPU Unit Built-in Inputs Only)
Operand
N
Inputs to a CS1W-INT01/CJ1W-INT01
Interrupt Input Unit (16 inputs/Unit)
Inputs to a CJ1M CPU Unit's Built-in Inputs
(4 inputs/Unit)
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Mnemonic Variations
MSKS @MSKS
Block program areas Step program areas
OK OK
Description
Interrupt Input
Interrupt Input
Interrupt Input
Function
code
Controls whether I/O interrupt tasks and sched-
690
uled interrupt tasks are executed.
MSKS
MSKS(690)
N: Interrupt identifier
N
C: Control data
C
Subroutines
OK
Data type
---
UINT
Contents
Interrupt Input No.
0: Unit number 0 (interrupt tasks 100 to 115)
1: Unit number 1 (interrupt tasks 116 to 131)
0: Unit number 0 (interrupt tasks 100 to 107)
1: Unit number 1 (interrupt tasks 108 to 115)
2: Unit number 2 (interrupt tasks 116 to 123)
3: Unit number 3 (interrupt tasks 124 to 131)
6: Interrupt input 0 (interrupt task 140)
7: Interrupt input 1 (interrupt task 141)
8: Interrupt input 2 (interrupt task 142)
9: Interrupt input 3 (interrupt task 143)
Interrupt Mask
Set to 0000 to FFFF hex
Bits 0 to 15 correspond to each interrupt task. Individual bit settings are as follows:
0: Enable (unmask) the interrupt.
1: Disable (mask) the interrupt.
Set to 0000 to 00FF hex
Bits 0 to 7 correspond to each interrupt task. Individual bit settings are as follows:
0: Enable (unmasks) the interrupt.
1: Disable (masks) the interrupt.
0000 hex: Enable (unmask) the interrupt (direct mode).
0001 hex: Disable (mask) the interrupt (direct mode).
0002 hex: Start decrementing counter and enable interrupt (counter mode).
0003 hex: Start incrementing counter and enable interrupt (counter mode).
Contents
Interrupt Input No.
2: Unit number 0 (interrupt tasks 100 to 115)
3: Unit number 1 (interrupt tasks 116 to 131)
10: Interrupt input 0 (interrupt task 140)
11: Interrupt input 1 (interrupt task 141)
12: Interrupt input 2 (interrupt task 142)
13: Interrupt input 3 (interrupt task 143)
3. Instructions
Function
SFC action or
Interrupt tasks
transition programs
OK OK
Size
1
1
3
703
