C: First Control Word
15
C
Number of words to receive
0001 to maximum data length (hex)
(Depends on network, for example
1 to 990 decimal (0001 to 03DE hex)
for Controller Link.)
15 12 11 8 7
C+1 0 0 0 0
Serial port number
0: Do not use.
Always 0.
1: Port 1
2: Port 2
3: Reserved.
4: Reserved.
15 8 7
C+2
Source node number (See note 3.)
00 to maximum node number (hex)
(Depends on network, for example
00 to 20 hex (0 to 32 decimal) for Controller Link.)
15 12 11
C+3 0 0 0 0 0 0 0 0
Response setting
0 hex: Response requested
8 hex: No response requested
15
C+4
Response monitoring time
1 to 65535 decimal (0001 to FFFF hex)
0.1 to 6,553.5 s
0000 hex: 2 s (default)
Note 1 Set the source network address in the routing tables unless you are specifying a local network. Set the source net-
work address to 00 for a local network. If there are more than one CPU Bus Unit connected in the PLC, the "local net-
work" is the network of the CPU Bus Unit with the lowest unit number.
2 The unit addresses are as follows:
• CPU Unit: 00 hex
• CPU Bus Unit: 10 hex + unit number (hex)
• Special I/O Unit: 20 hex + unit number (hex) (Except for C200H Special I/O Units)
• Inner Board: E1 hex (CS Series only)
• Computer: 01 hex
• Unit connected to network: FE hex (Eliminates the need to specify the unit number of the remote Unit.)
The serial port unit address are as follows:
• Serial Communications Units:
Port 1: 80 hex + 04 hex
Port 2: 81 hex + 04 hex
• Serial Communications Boards:
Port 1: E4 hex (228 decimal)
Port 2: E5 hex (229 decimal)
• CPU Unit
Peripheral port: FD hex (253 decimal)
RS-232C port: FC hex (252 decimal)
3 Broadcasting is not possible for RECV2(492). Set 00 hex to request a reception from the local node.
CS/CJ/NSJ Series Instructions Reference Manual (W474)
0
0
Source network address
(See note 1.), 00 to 07
0
Source unit address
(See note 2.)
4 3 0
Number of retries
Always 0.
0 to F hex (0 to 15 decimal)
0
unit number
unit number
I: First communications information word
Clear D and I words before executing the instruction.
15
I
System work
area
15
I+1
Communications completion code: 0000 to FFFF hex
3. Instructions
1 0
Execution Completed Flag
0: Not completed.
1: Execution completed
Error Flag
0: No error
1: Error
0
