ASL/ASLL
Instruction
ARITHMETIC SHIFT LEFT
DOUBLE SHIFT LEFT
Symbol
Applicable Program Areas
Function block
Area
definitions
Usage OK
Operands
Operand
Wd Word
Operand Specifications
Word addresses
Area
CIO WR HR
ASL Wd
OK OK OK
ASLL Wd
Flags
Name
Error Flag
Equals Flag
Carry Flag
Negative Flag
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Mnemonic Variations
ASL @ASL
ASLL @ASLL
ASL
ASL(025)
Wd
Wd: Word
Block program areas Step program areas
OK OK
Description
AR T C DM EM
OK OK OK OK OK
Label
ER OFF
= • ON when the shift result is 0.
• OFF in all other cases.
CY • ON when 1 is shifted into the Carry Flag (CY).
• OFF in all other cases.
N • ON when the leftmost bit is 1 as a result of the shift.
• OFF in all other cases.
Function
code
025 Shifts the contents of Wd one bit to the left.
570 Shifts the contents of Wd and Wd +1 one bit to the left.
Subroutines
OK
Data type
ASL
UINT UDINT
Indirect DM/EM
addresses
Con-
stants
@DM *DM
DR
@EM *EM
OK
OK OK ---
---
Operation
3. Instructions
Function
ASLL
ASLL(570)
Wd
Wd: Word
SFC action or transition
Interrupt tasks
programs
OK OK
Size
ASLL ASL ASLL
1
Registers Flags
Pulse
bits
Indirect
IR TK CF
using IR
--- OK --- --- ---
3
2
TR
bits
---
307
