Connecting Cables

Connecting Cables

Note
Step 1
Step 2
Step 3
Step 4
Step 5
Caution
Note
Step 6
Cisco Content Engine 511 and 566 Hardware Installation Guide
3-12
Download from Www.Somanuals.com. All Manuals Search And Download.
Follow these steps to connect network, console, and SCSI cables to the
Content Engine.
The SCSI cable is part of the Cisco Storage Array accessory kit. If you did not
order the Cisco Storage Array, you did not receive a SCSI cable.
For network connections, insert a Category 5 UTP cable into the Ethernet 1 or
Ethernet 2 receptacle on the Content Engine back panel. (See
Connect the other end of the network cable to a hub or switch in your
network.
For console connections, plug the serial cable into the serial port on the
Content Engine back panel.
Connect the other end of the console cable to a console or a communications
server.
If you are using a Cisco Storage Array as an external storage device, attach the
SCSI cable to the SCSI LVD port.
Make sure to tighten the jackscrews on the SCSI cable.
SCSI port is available only on CE-566 model.
Connect the other end of the SCSI cable to the appropriate port on the
Storage Array.
For further information about the Cisco Storage Array, refer to the
Cisco Storage Array Installation and Configuration Guide publications.
Chapter 3 Installing the Content Engine
Figure 3-9.)
OL-5756-01
