Cisco CE-511 Hardware Installation Manual page 38

Hardware Features
Cisco ACNS software does not support the use of a keyboard or mouse (Personal
Note
System 2 [PS/2] or Universal Serial Bus [USB]) with the Content Engine.
However, keyboard and mouse are supported by the BIOS for power-on self-test
(POST), and the configuration/setup utility.
Table 1-7
Table 1-7
Item
AC power receptacle
Ethernet 1 port
Ethernet 2 port
Serial port
SCSI LVD port (CE-566
only) (See
Fibre Channel port (on
optional adapter)
Audio/video port (on
optional MPEG A/V
decoder adapter)
1. SAN = storage area network
2. BNC = Bayonet Neill-Concelman
3. RGB = red green blue
4. S/PDIF = Sony/Philips Digital Interface
5. VGA = video graphics array
Cisco Content Engine 511 and 566 Hardware Installation Guide
1-12
Download from Www.Somanuals.com. All Manuals Search And Download.
describes the back panel ports and receptacles.
Back Panel Ports and Connectors
Description
The AC power cord connects to this plug.
This 10/100/1000BASE-T port is autosensing with
full-duplex capability; it connects your
Content Engine to the Ethernet LAN.
This 10/100/1000BASE-T port is autosensing with
full-duplex capability; it connects your
Content Engine to the Ethernet LAN.
This is a standard serial port for connecting to a
console or terminal.
Use this port to attach an external Cisco
Figure 1-2) Storage Array device.
This port provides the option to connect to an
external Fibre Array device or SAN
storage capacity.
3 BNC
•
composite video output
Mini-XLR 8-pin connector for S/PDIF
•
analog stereo audio output
Mini-XLR 8-pin connector for VGA
•
Chapter 1 Introducing the Content Engine
2
connectors for YUV, RGB
1
for added data
3
, and
4
and
5
output
OL-5756-01
