Installing Adapters

Installing the Fibre Channel Adapter

Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Step 8
Step 9
Step 10
Step 11
Step 12

Troubleshooting the Fibre Channel Adapter Installation

Cisco Content Engine 511 and 566 Hardware Installation Guide
4-10
Download from Www.Somanuals.com. All Manuals Search And Download.
To install the Fibre Channel adapter, follow these steps:
Check the system board and locate the correct PCI-X slot for the Fibre Channel
card.
Power down any connected peripheral devices and then power down the Content
Engine.
Disconnect the power cords.
Remove the cover. (See the
page 4-1.)
Remove the expansion slot cover. (See
Align the adapter with the slot 2 connector on the riser card. Carefully press the
adapter into the expansion slot until it is fully seated and secure. (See
Reinstall the riser card. Make sure that the riser card is fully seated in the riser
card connector on the system board.
Connect one end of an LC-LC Fibre Channel cable to the optical interface
connector on the Fibre Channel adapter card. Connect the other end to a Fibre
Channel device.
Carefully install and secure the cover. (See the
section on page 4-16.)
Connect the power cables.
Power on all external Fibre Channel devices; then power on the Content Engine.
Verify the installation by checking the LEDs. (See
Three types of adapter installation problems might cause your Fibre Channel
adapter to function incorrectly:
Hardware problems
•
System configuration problems
•
Fibre Channel problems
•
Chapter 4
"Removing the Cover and Bezel" section on
Figure 4-3.)
"Completing the Installation"
Installing Hardware Options
Figure
Table 1-6 on page 1-10.)
OL-5756-01
4-4.)
