Cisco CE-511 Hardware Installation Manual page 44

Specifications
Table 1-10
Specification
Fibre Channel adapter
MPEG A/V decoder
adapter
Power supply
Cisco Content Engine 511 and 566 Hardware Installation Guide
1-18
Download from Www.Somanuals.com. All Manuals Search And Download.
CE-511 and CE-566 Hardware Specifications (continued)
Description
Bus type: Fiber-optic media (shortwave
•
50-micron)
Bus transfer rate: 2 gigabits per second (Gbps)
•
maximum at half duplex and 4 Gbps at full
duplex
Protocols: Supports FCP
•
Video specifications
2
S/N: 10 kHz to 4.2 MHz; Y: 65 dB rms
•
Pb: 70 dB rms; Pr: 70 dB rms
Frequency response: 0 to 4.0 MHz ± 2 dB
•
Sync tip: 40 IRE
•
Luma nonlinearity: 5%
•
Audio specifications
•
5
• S/PDIF
PCM
–
bitstream out
75-ohm, 0.5-V p-p
–
Rise and fall time: > 0.4 microseconds
–
measured from 10 to 90%
Analog
•
– Jumper-selectable balanced or unbalanced
audio (balanced = +4 dBm)
Frequency response: 20 Hz to 22 kHz ±
–
0.5 dB
Reference level: 0.5-V p-p ± 10%
–
THD
–
1 AC-input
Chapter 1 Introducing the Content Engine
1
-SCSI protocol
4
± 4
6
or compressed audio coding 3 (AC-3)
7
± 20%
8
+n:@20 Hz to 22 kHz < 0.5%
3
;
OL-5756-01
