Working with Hard Disk Drives

Working with Hard Disk Drives

Installing a Hard Disk Drive in the CE-511
Note
Note
Caution
Step 1
Step 2
Step 3
Step 4
Cisco Content Engine 511 and 566 Hardware Installation Guide
4-12
Download from Www.Somanuals.com. All Manuals Search And Download.
This section describes how to install a hard disk drive in the Content Engine. The
CE-511 requires a Serial Advanced Technology Attachment (SATA) hard disk
drive. CE-566 supports two 1-inch (2.54-cm) slim 3.5-inch (8.89-cm) LVD hard
disk drives. The CE-566 requires a SCSI hard disk drive.
To install a simple-swap SATA hard disk drive in a bay, complete the following
steps.
All hard disk drives being used in the Content Engine should have the same
throughput speed rating. Mixing hard disk drives with different speed ratings will
cause all hard disk drives to operate at the lower throughput speed.
If your Content Engine has only one hard disk drive, install it in the left drive bay.
To maintain proper system cooling, do not operate the Content Engine for more
than 10 minutes without either a hard disk drive or a filler panel installed in
each bay.
Inspect the new drive for any signs of damage.
Review the information in the
"Safety Guidelines" section on page
Power down the Content Engine and peripheral devices, and disconnect the power
cord and all external cables.
Press the release tabs on the bezel and pull the bezel away from the
Content Engine. (See
"Safety Warnings" section on page
2-4.
Figure 4-2.)
Chapter 4 Installing Hardware Options
2-1, and the
