Chapter 3 Installing the Content Engine
Figure 3-7
1
2
3
1
3
Align the slide rail assembly to the front flange on the rack, and insert and tighten
Step 5
two M6 screws to secure the slide rail to the front flange. (See
Repeat
Note
OL-5756-01
Download from Www.Somanuals.com. All Manuals Search And Download.
Attaching the Slide Rails to the Rack
Rear
Tab
Rear flange
Step 4 and Step 5 to install the other slide rail assembly.
If it is necessary to adjust the length of the slide rail, loosen the
adjustment screw (labeled 2 in
then adjust the length of the slide rail and tighten the adjustment screw.
Cisco Content Engine 511 and 566 Hardware Installation Guide
Installing a CE-511 or CE-566 Unit
Front
2 Adjustment screw
Figure 3-7) on the rear of the slide rail;
Figure 3-7.)
3-9
