Preparing And Installing A Fibre Channel Adapter - Cisco CE-511 Hardware Installation Manual

Installing Adapters
Step 7
Step 8
Caution
Step 9
Step 10
Step 11
Step 12
Step 13

Preparing and Installing a Fibre Channel Adapter

Cisco Content Engine 511 and 566 Hardware Installation Guide
4-8
Download from Www.Somanuals.com. All Manuals Search And Download.
Touch the static-protective package containing the adapter to any unpainted metal
surface on the Content Engine and then remove the adapter from the
static-protective package. Avoid touching the components and gold-plated edge
connectors on the adapter.
Place the adapter, component-side up, on a flat, static-protective surface and set
any jumpers or switches as described by the adapter manufacturer, if necessary.
When you install an adapter in the Content Engine, be sure that it is completely
and correctly seated in the PCI expansion slot before you power up the
Content Engine. Incomplete insertion might cause damage to the system board or
the adapter.
To install the adapter, carefully grasp the adapter by its top edge or upper corners,
align it with the PCI-X slot 1 connector (labeled 2 in
the adapter firmly into the expansion slot.
Reinstall the riser card. Make sure that the riser card is fully seated in the riser
card connector (labeled 5 in
Tighten the captive screw for expansion slot 1.
Connect the required cables to the adapter.
If you have other hardware options to install, do so now; otherwise, go to the
"Completing the Installation" section on page
Fibre Channel is a high-speed data transport technology used for mass storage and
networking. Fibre Channel technology is outlined in the SCSI-3 Fibre Channel
Protocol (SCSI-FCP).
The Fibre Channel adapter uses a multimode shortwave optical interface for
distances up to 1640 feet (500 meters). It is a 2-gigabit (Gb) Fibre Channel device
that supports data transfer rates up to 200 megabytes per second (MBps) half
duplex and 400 MBps full duplex on optical interfaces.
Chapter 4
Figure 4-4) on the system board.
4-16.
Installing Hardware Options
Figure 4-4), and then press
OL-5756-01
