Installing Adapters
Figure 4-3 Removing the Expansion Slot Cover
1
Expansion slot cover (slot 2)
3
Captive screw
Step 6
Cisco Content Engine 511 and 566 Hardware Installation Guide
4-6
Download from Www.Somanuals.com. All Manuals Search And Download.
1
2
Remove the riser card (labeled 1 in
the expansion slot.
Chapter 4
4
3
2
Expansion slot cover (slot 1)
4
Riser card assembly
Figure 4-4) from the system board to access
Installing Hardware Options
