C H A P T E R
Cabling and Configuring the
CES Port Adapter Modules
This chapter describes cabling and configuration procedures for the LightStream 1010
asynchronous transfer mode (ATM) switch circuit emulation service (CES) T1 and E1 port
adapter modules (PAMs). When your switch leaves the factory, it is configured as specified
in your order and is ready for installation and startup. As your communication requirements
change, you might want to upgrade your system, add components, or change the initial
configuration.
The following CES T1 and E1 PAMs are described in this chapter:
•
•
•
Software and upgrades require specific document part numbers and other frequently
updated information; therefore, only basic software configuration guidelines are included
in this publication. Detailed, up-to-date instructions are included in the LightStream 1010
ATM Switch Software Configuration Guide and command line interface (CLI) command
descriptions are provided in the LightStream 1010 ATM Switch Command Reference.
This chapter contains the following information:
•
•
•
8
CES T1 Twisted-pair Port Adapter Module
CES E1 Twisted-pair Port Adapter Module
CES E1 BNC Port Adapter Module
Overview of the CES Port Adapter Modules
Connecting the Interface Cables and Checking the LEDs
Configuring the Interfaces
Cabling and Configuring the CES Port Adapter Modules 8-1
