Installing a CE-511 or CE-566 Unit
Step 1
Figure 3-2 Installing the Chassis in the Rack
Front
Step 2
Step 3

Installing the Chassis in a 4-Post Rack

Cisco Content Engine 511 and 566 Hardware Installation Guide
3-4
Download from Www.Somanuals.com. All Manuals Search And Download.
To install a Content Engine in a 2-post rack, follow these steps:
Attach a bracket to one side of the chassis, aligning the front flange of the bracket
with the hash mark on the side of the chassis. (See
Attach a second bracket to the opposite side of the chassis in the same manner.
After you secure the brackets to the chassis, rack-mount the chassis by securing
the brackets to two posts or mounting strips in the rack. You need two people to
install the chassis in the rack—one person to hold the chassis and one person to
secure it to the rack.
The inlet and exhaust ports for cooling air are located in the front and rear of the
chassis, respectively; therefore, multiple Content Engines can be stacked with
little or no vertical clearance.
Figure 3-3 shows the items that you need to install the Content Engine in a 4-post
rack. If any items are missing or damaged, contact your place of purchase.
Chapter 3 Installing the Content Engine
Figure 3-2.)
Rear
OL-5756-01
