Chapter 3 Installing the Content Engine
Figure 3-5
1
3
Place an inner slide rail at the alignment marker (labeled 1 in
Step 3
indicated by the arrow on the side of the Content Engine. Use two M4 screws to
secure the inner slide rail to the Content Engine.
Repeat this step to attach the other inner slide rail to the Content Engine.
OL-5756-01
Download from Www.Somanuals.com. All Manuals Search And Download.
Removing the Inner Slide Rail
1
Slide rail assembly
Inner slide rail
Cisco Content Engine 511 and 566 Hardware Installation Guide
Installing a CE-511 or CE-566 Unit
2
2 Release latch
Figure
3
3-6) as
3-7
