Removing the Cover and Bezel

Figure 4-1 Removing the Content Engine Cover
Step 4
Caution
Step 5
Cisco Content Engine 511 and 566 Hardware Installation Guide
4-2
Download from Www.Somanuals.com. All Manuals Search And Download.
Slide the cover back; then lift it up and off the Content Engine.
For proper cooling and airflow, replace the cover before turning on the
Content Engine. Operating the Content Engine for extended periods (over
30 minutes) with the cover removed might damage Content Engine components.
Remove the bezel as shown in
Press the release tabs on the bezel and pull the bezel away from the
a.
Content Engine.
Store the bezel in a safe place.
b.
Chapter 4
1
Figure 4-2.
Installing Hardware Options
