Chapter 4
Installing Hardware Options
Step 5
Figure 4-5
Installing a SATA Hard Disk on CE-511
Hard disk drive
OL-5756-01
Download from Www.Somanuals.com. All Manuals Search And Download.
Install the hard disk drive in the bay.
Align the drive assembly (see
a.
Gently push the drive assembly into the drive bay until the drive connects to
b.
the backplane.
Check the hard disk drive status LED to verify that the hard disk drive is
c.
operating properly.
If the amber hard disk drive status LED for a drive is lit continuously, that
individual drive is faulty and needs to be replaced. If the green hard disk drive
activity LED is flashing, the drive is being accessed.
SATA hard disk
drive connector
Cisco Content Engine 511 and 566 Hardware Installation Guide
Working with Hard Disk Drives
Figure
4-5) with the guide rails in the bay.
