Chapter 1 Introducing the Content Engine
Figure 1-7 Back Panel LEDs
1 Ethernet 1 link
3
Ethernet 2 activity
Table 1-5 Back Panel LEDs
Indicator
Ethernet 1 link
Ethernet 1 activity
Ethernet 2 activity
Ethernet 2 link
OL-5756-01
Download from Www.Somanuals.com. All Manuals Search And Download.
1 2
4
Color State
Green On
Off
Green Blinking
Green Blinking
Green On
Off
Figure 1-8 shows the LEDs for the Fibre Channel adapter, and
their function.
Cisco Content Engine 511 and 566 Hardware Installation Guide
3
2 Ethernet 1 activity
4
Ethernet 2 link
Description
Indicates that the speed of the Ethernet LAN is
1000BASE-TX.
Indicates that the speed of the Ethernet LAN is
10BASE-T/100BASE-TX.
Indicates that there is an active link connection on
the 10/100/1000BASE-T interface for Ethernet
port 1.
Indicates that there is an active link connection on
the 10/100/1000BASE-T interface for Ethernet
port 2.
Indicates that the speed of the Ethernet LAN is
1000BASE-TX.
Indicates that the speed of the Ethernet LAN is
10BASE-T/100BASE-TX.
Hardware Features
Table 1-6 describes
