Pneumatic specifications

CAUTION
Gas supplies

ACGO port relief

11-6
All gases supplied to the system must be medical grade.
Pipeline gases
Cylinder gases
Cylinder connections
Primary regulator output
pressure
Pressure-relief valve
Pipeline connections
(filtered)
Pressure displays
Pipeline inlet pressure
N2O shutoff
A relief valve on the ACGO outlet limits the fresh gas pressure at the
ACGO port to 12.25 kPa (125 cmH2O) between 25 l/min and 75 l/
min.
O2, Air, N2O
O2, Air, N2O (3 cylinder maximum)
Pin indexed
Nut and gland DIN-477
Large cylinder kit available for O2 and N2O
Pin indexed: The primary regulator is set to
pressure less than 345 kPa (50 psi).
DIN-477: The primary regulator is set to
pressure less than 414 kPa (60 psi).
Approximately 758 kPa (110 psi)
DISS-Male; DISS-Female; AS 4059
(Australian); S90-116 (French Air Liquide);
NIST (ISO 5359). All fittings available for O2,
Air, and N2O.
On system display.
280-600 kPa (41-87 psi)
3.5 to 27.6 kPa (0.5 to 4 psi)
