F2–02DAS-2 Isolated 2 Channel Voltage Analog Output
Number of Channels 2, isolated (2 commons)
Output Ranges 0–5VDC, 0–10VDC
Resolution 16 bit (1 in 65536)
"
Isolation voltage 750V continuous, channel to channel,
channel to logic
Load Impedance 2K ohms min.
PLC update rate 1 channel per scan minimum
(D2–230 CPU)
2 channels per scan minimum
(D2–240 or D2–250 CPU)
"10 counts ("0.015% of full scale)
Linearity Error
(end to end) maximum
Conversion Settling 3ms to o.1% of full scale
time
"32 counts ("0.05%)
Gain Calibration Error
Offset Calibration Error "13 counts ("0.02%)
One count in the specification table is equal to one least significant bit of the analog data value (1 in 65536).
NOTE 1: Shields should be connected to the 0V.
NOTE 2: Load must be within compliance voltage.
NOTE 3: For non–isolated outputs, connect 0V1 to 0V2.
User Wiring
Note 3
Loop
–
Supply
+
24VDC
CH1
2kW
Note 1
Note 2
Loop
–
Supply
+
24VDC
CH2
2kW
Note 1
Note 2
Maximum Inaccuracy
Digital outputs
Output points
required
Power Budget
Requirement
External Power
Supply
Operating
Temperature
Storage Temperature
Relative Humidity
Environmental air
Vibration
Shock
Noise Immunity
Internal module circuitry
0V1
+V1
CH1-V
CH1+V
N/C
N/C
0V2
+V2
CH2-V
CH2+V
I/O Wiring and Specifications
"0.07% @ 77°F (25°C)
"0.18% @ 32 to 140°F (0 to 60_C)
32 (Y) output points
16 binary data bits, 2 channel ID bits
100 mA @ 5 VDC (supplied by base)
21.6–26.4 VDC, 60 mA / channel
32 to 140° F (0 to 60_ C)
–4 to 158° F (–20 to 70_ C)
5 to 95% (non-condensing)
No corrosive gases permitted
MIL STD 810C 514.2
MIL STD 810C 516.2
NEMA ICS3–304
OUT
F2-02DAS–2
0-5VDC
0-10VDC
Voltage source
D/A
Voltage source D/A
F2–02DAS–2
DL205 Installation and I/O Manual, Rev. B
3–49
ANALOG
2CH
0V1
+V1
CH1–V
CH1+V
N/C
N/C
0V2
+V2
CH2–V
CH2+V
