Environmental The following table lists the environmental specifications that generally apply to the
Specifications DL205 bases and I/O modules (Be sure to check the specifications of the CPU-slot
controller you are using). I/O module operation may fluctuate depending on the
ambient temperature and your application. Please refer to the appropriate I/O
module specifications for the temperature derating curves applying to specific
modules.
Specification
Storage temperature
Ambient operating temperature
Ambient humidity*
Vibration resistance
Shock resistance
Noise immunity
Atmosphere
*Equipment will operate below 30% humidity. However, static electricity problems occur much more
frequently at lower humidity levels. Make sure you take adequate precautions when you touch the
equipment. Consider using ground straps, anti-static floor coverings, etc. if you use the equipment in
low humidity environments.

Power

The power source must be capable of supplying voltage and current complying with
the base power supply specifications.
Specification
Part Numbers
Input Voltage Range
Maximum Inrush Current
Maximum Power
Voltage Withstand (dielectric)
Insulation Resistance
Auxiliary 24 VDC Output
Fusing (internal to base
power supply)

Agency Approvals

Some applications require agency approvals. Typical agency approvals which your
application may require are:
AC Powered Bases
D2–03B–1,
D2–04B–1,
D2–06B–1,
D2–09B–1
100–240 VAC
+10% –15%
30 A
80 VA
1 minute @ 1500 VAC between primary, secondary, field ground, and run relay
> 10 M W at 500 VDC
20–28 VDC, less than 1V p-p
300 mA max.
non–replaceable 2A @ 250V
slow blow fuse; external fus-
ing recommended
•
UL (Underwriters' Laboratories, Inc.)
•
CSA (Canadian Standards Association)
•
FM (Factory Mutual Research Corporation)
S
CUL (Canadian Underwriters' Laboratories, Inc.)
Installation and Wiring
Rating
–4° F to 158° F (–20° C to 70° C)
32° F to 131° F (0° C to 55° C)
30% – 95% relative humidity (non–condensing)
MIL STD 810C, Method 514.2
MIL STD 810C, Method 516.2
NEMA (ICS3–304)
No corrosive gases
24 VDC Powered Bases
D2–03BDC1–1,
D2–04BDC1–1,
D2–06BDC1–1,
D2–09BDC1–1
10.2 – 28.8VDC (24VDC)
with less than 10% ripple
10A
25W
None
non–replaceable 3.15A @
250V slow blow fuse; exter-
nal fusing recommended
DL205 Installation and I/O Manual , Rev. B
2–7
125 VDC Powered Bases
D2–06BDC2–1,
D2–09BDC2–1
104–240 VDC
+10% –15%
20A
30W
20–28 VDC, less than 1V p-p
300 mA max.
non–replaceable 2A @ 250V
slow blow fuse; external fus-
ing recommended
