Panel Mounting
It is important to design your panel properly to help ensure the DL205 products
and Layout
operate within their environmental and electrical limits. The system installation
should comply with all appropriate electrical codes and standards. It is important the
system also conforms to the operating standards for the application to insure proper
performance. The diagrams below reference the items in the following list.
   Â
OK
   Â
 Â
Airflow
Temperature
Probe
Power
Source
È
Panel
Panel Ground
Terminal
Ç
Star Washers
     Â
     Â
1. Mount the bases horizontally to provide proper ventilation.
2. If you place more than one base in a cabinet, there should be a minimum of
7.2" (183mm) between bases.
3. Provide a minimum clearance of 2" (50mm) between the base and all sides
of the cabinet. There should also be at least 1.2" (30mm) of clearance
between the base and any wiring ducts.
4. There must be a minimum of 2" (50mm) clearance between the panel door
and the nearest DL205 component.
Note: The cabinet configuration below is not suitable for EU installations.
Refer to Appendix A European Union Directives.
Æ
À
2"
DL205 Base
Â
50mm
min.
À
Å
BUS Bar
Ground Braid
Copper Lugs
Earth Ground
Ç
Star Washers
Installation and Wiring
     Â
2"
50mm
Â
min.
Â
2"
50mm
min.
Â
2"
50mm
min.
Ä
Panel or
Single Point
Ground
Note: there is a minimum of 2" (50mm)
clearance between the panel door
or any devices mounted in the panel door
and the nearest DL205 component
DL205 Installation and I/O Manual , Rev. B
2–5
À
Ã
