Discrete Input
The discrete modules provide LED status indicators to show the status of the input
points.
Module Status
Indicators
Color Coding of I/O
The DL205 family of I/O modules have a color coding scheme to help you quickly
Modules
identify if the module as either an input module, output module, or a specialty
module. This is done through a color bar indicator located on the front of each
module. The color scheme is listed below:
Terminal Cover
(installed)
À
I/O Wiring and Specifications
Status indicators
Wire tray area
behind terminal cover
Color Bar
Module Type
Discrete/Analog Output
Discrete/Analog Input
Other
DL205 Installation and I/O Manual, Rev. B
3–15
Terminal
Color Code
Red
Blue
White
