DL205 System I/O Components
Bases
Four base sizes are available: 3 slot, 4 slot, 6 slot, and 9 slot. One slot is for the
DL205 Controller/Slave module, the remaining slots are for I/O modules. All bases
include a built-in power supply.
I/O Configuration
The number of I/O points that can be supported is CPU–slot controller dependent.
I/O Modules
The DL205 has some of the most powerful modules in the industry. A complete
range of discrete modules which support 24 VDC, 110/220 VAC and up to 10A relay
outputs are offered. The analog modules provide 12 and 16 bit resolution and
several selections of input and output signal ranges (including bipolar). At this time,
the only specialty module supported is the H2–CTRIO when used with an H2–EBC
or H2–WPLCx–xx controller.
Getting Started
DL205 Installation and I/O Manual, Rev. B
1–5
